The palletizing and conveying line is an automatic supporting equipment at the back end of the dry mix mortar production line, integrating belt conveying, bag leveling, weight re-inspection, automatic palletizing, pallet conveying and finished product stacking. It can be connected with various valve bag packing machines to realize fully automatic unmanned operation of bagged mortar from discharging, conveying and detection to palletizing and warehousing. Adopting modular steel frame structure, the equipment operates stably with accurate positioning and high palletizing regularity. It is suitable for 20–50kg bagged dry powder materials, supports multi-layer stacking and automatic pallet replacement. It greatly replaces manual palletizing, reduces labor costs and improves storage and transportation efficiency, and supports two modes of small and medium manipulator palletizing and large robot full-automatic palletizing.
Core Components: Belt conveying frame, automatic leveling and pressing mechanism, on-line weight checking device, automatic pallet conveying system, palletizing actuator, electric control intelligent system, safety protection device.
Product Advantages: Fully automatic operation without manual intervention, greatly reducing labor costs; stable conveying and accurate palletizing positioning ensure neat finished product stacking and no collapse; compatible with multi-specification bagged materials and various mortar production lines; low operating noise and low failure rate with strong continuous operation stability; it can be connected with the storage system to realize integrated pipeline operation of production, palletizing and warehousing.
| Parameter Item | Technical Specification |
| Equipment Name | Dry Mortar Simple Grabber Palletizer |
| Applicable Bags | 5-10kg smallmortar bags,20-50kg standard valve bags |
| Palletizing Capacity | 300-500 bags/hour |
| Stacking Layers | 8-14 layers/pallet(adjustable) |
| Stacking Pattern | Cross alternating stacking,orderly and anti-collapse |
| Applicable Pallet Size | 1200*1000mm/1100*1100mm(customizable) |
| Working Power Supply | 380V 50Hz Three-phase Four-wire |
| Total Power | 7.5KW(standard model) |
| Air Source Pressure | 0.4-0.6MPa(clean compressed air) |
| Control System | PLC +Touch Screen Automatic Control |
| Stacking Precision | Position deviation≤±5mm,stable stacking without collapse |
| Equipment Dimension | 3200*2800*3500mm |
| Equipment Weight | 1200kg |
| Working Temperature | -10℃~45℃ |
| Continuous Operation | Support 24-hour intermittent &continuous production |
